Thermal Analysis with Solidworks Simulation 2022 and Flow Simulation 2022

Thermal Analysis with SOLIDWORKS Simulation 2022 goes beyond the standard software manual. It concurrently introduces the reader to thermal analysis and its implementation in SOLIDWORKS Simulation using hands-on exercises. A number of projects are presented to illustrate thermal analysis and related topics. Each chapter is designed to build on the skills and understanding gained from previous exercises.

Thermal Analysis with SOLIDWORKS Simulation 2022 is designed for users who are already familiar with the basics of Finite Element Analysis (FEA) using SOLIDWORKS Simulation or who have completed the book Engineering Analysis with SOLIDWORKS Simulation 2022. Thermal Analysis with SOLIDWORKS Simulation 2022 builds on these topics in the area of thermal analysis. Some understanding of FEA and SOLIDWORKS Simulation is assumed.

Topics covered

• Analogies between thermal and structural analysis
• Heat transfer by conduction
• Heat transfer by convection
• Heat transfer by radiation
• Thermal loads and boundary conditions
• Thermal resistance
• Thermal stresses
• Thermal buckling
• Modeling techniques in thermal analysis
• Presenting results of thermal analysis
